HDSW24UL
24VDC Heavy-Duty Variable Speed Swing Gate Operator
- Ideal for heavy gate and extreme applications.
- Rated for gates up to 22 ft. or up to 2,800 lbs, 4,500 lbs. with optional arm.
- Variable cycle speed of 13 – 36 sec for a 90 degree opening.
- Integrates easily with LiftMaster Access Control Technology.
Features
Gate Safety and Security
Sync
Synchronizes gate operation and eliminates costly trenching; set speed independently if needed.
UL Listed
Tested to the most stringent UL 325 industry guidelines. External entrapment protection devices need to be added to meet UL 325 standards. Your Installer will recommend suitable entrapment protection devices for your installation, such as photoelectric or edge sensors.
Gate Safety Sensors
Protect people entering or leaving your gate with safety sensors that stop the gate from closing on obstructions.
HD Gate Power
Variable Cycle Speed
Adjusts to meet application needs 13 – 36 sec for a 90 degree opening
For Gates up to 22 Feet
Rated for heavy gates up to 22 feet in length or up to 4,500 LBS (with otional arm HDLGARM).
Continuous Duty Operation
Custom 1.5 HP peak brushless 24VDC motor delivers up to 6 million cycles. Custom large size 80 gear box.
Business Connectivity
LiftMaster’s powerful combination of innovative myQ® technology and reliable hardware seamlessly connects community and facility access points for a complete, real-time view of multiple entrances across multiple properties that enhances security and reduces liability.
With 24/7 monitoring capabilities and real-time activity alerts, myQ Community is a scalable, cloud-based platform that lets you conveniently manage and control multiple access points across all communities in your portfolio from a single dashboard.
Unlock the power of real-time data, insights and reporting with myQ Smart Facility Access. Analyze your commercial doors, docks and gates and get operational data to better manage productivity, maintenance, access control and compliance.
Specifications
Voltage
120/240 VAC Single Phase
Battery Backup
YES
myQ Compatibility
YES
Solar
Solar-ready
Variable Speed
Yes
Motor Power
1.5 HP Peak Brushless Motor
Soft Start / Stop
YES
Operator Duty Rating
Continuous Duty, High-Cycle, High-Temperature
UL Usage Classification
I, II, III & IV
Warranty
- Operator Warranty: 7 Years Residential, 5 Years Commercial
What's included
Compatibility
- HomeLink® Compatible
Compatibility Bridge™ (not included) necessary for certain vehicles. Visit bridge.liftmaster.com to find out if a Bridge is needed.
HomeLink® is a registered trademark of Gentex Corporation.
