EVO FEATURES
- Built-In HID Card Reader
- Up to 1,500 Directory Listings
- Calls up to 6 App Contacts and 3 Voice Only Numbers Per Directory Listing
- 1 Wiegand Expansion Port
- Wiegand Functionality for any 26-bit Reader
- Manage Up to 2 Gates or Doors
- Brilliant 7” Color Touchscreen
CELLGATE EXCLUSIVES
- Streaming Video Telephone Entry
- Verizon or AT&T LTE Service *No VoIP Fees Required
- Plug-and-Play Internet Option *No VoIP Fees Required
- CellGate TrueCloud Hosted by Microsoft Azure EVO FEATURES
- Additional Wiegand Expansion Capability
NEW EXCLUSIVE External Camera Options
- Pixel Activated Video
- All Video Stored on Camera
- Cloud-Stored Still Photos
Property Management Benefits
- System Implementation Support
- Automated Enrollment Process
- Tenant Self-Serve Call Group Management
- Manage Multiple Location via CellGate Portal
- No Software Required
- Time/Date Restrictions for Wiegand Credentials
- Control Gate/Door On Demand or with a Schedule
Tenant Benefits
- See Live Video of Visitors
- Easy to Use iOS/Android App
- Tenant Managed Call Groups
- Cellular Carrier and Signal Strength Verification
- Peace of Mind through Increased Security
Dealer Benefits
- Easy 6-Wire Installation
- Pre-Configured System
- End-to-End Support
- Cellular Carrier and Signal Strength Verification
- Post-Installation Testing Credentials Provided
Specifications
External Camera Options
Bullet Cameras
- 3-10.5mm Varifocal Lens
- 5-64mm Varifocal Lens
- 4mm Fixed Focal Lens
Dome Camera
- 3-10.5mm Varifocal Lens
HD Camera angles
- Horizontal: 120°
- Vertical: 64°
W460 Power Consumption (12v DC):
- Multi Family: 1A External
- Cam: 350mA
1 – Wiegand Expansion Port (26 bit)
2 Relays
- Contact rating: 0.5A @ 125vAC, 3A@30v DC
- Switching voltage: 277v AC, 220v DC
- Switching current: 4A
2 Digital inputs
IP65
Operating Temperature
-20°C – 55°C -4°F – 131°F
Dimensions (excluding antenna)
- Height- 302mm
- Width- 156mm
- Depth- 140mm (top), 120mm (bottom)
Cellular Technology/Networks
- 3G/LTE AT&T and Verizon
- VoIP (no additional service required)
- Full-time IP connection
Internet
plug and play VPN – no router configuration
Included in box
- Watchman EVO
- Power supply – 5A
- Magnetic switch
- Installation manual & user manual
Mounts available
- Pedestal Mount Recessed
- Mount (Optional Kit)
Antenna Options
- L-bracket
- Directional panel
- Signal booster
CellGate TrueCloud
- Web-Based Access
- Event Logs and Records with Pictures
- Create and Store Time/Date Restricted Access Credentials
- Manage Notifications
- Custom Administrative Privileges
- Events Stored for 6 Months
Watchman EVO App
- Receive Video/Audio Calls from Visitors without Credentials
- Live Video from Entrance
- Open Gate from Anywhere
CellGate App
- Property Management Functionality
- Open or Hold Open On Demand
- Close On Demand (Override Holds)
- Take Photos from Internal and External Cameras Resident Functionality
- Momentary Open Only
