Doorking 1835

1835 PC PROGRAMMABLE TELEPHONE ENTRY SYSTEM

Provides both resident and visitor Access Control into and within apartment buildings, gated communities, condominiums, office buildings, factories and industrial sites
PC Programmable. Programming and Transaction Analysis Software included
Voice and Data (programming) Connection over either Cellular, Internet, or copper POTS lines
Built-In Electronic Directory
Large easy-to-use A-Z-CALL Buttons
Resident Access Control is provided by means of Cards, Digital PIN Codes, or Wireless Transmitters
2-Year Limited Factory Warranty

Up to 48 entry points

Lit keypad and A-Z-CALL buttons

Easy to use software included

Use DKS service options for connection and programming

Stainless Steel Faceplate
Galvanized Steel Sub-Plate
Metal Keypad, with internally lit LED Keypad and A-Z-CALL buttons
Offset Speaker Holes for protection
Hands-Free Voice Operation (Optional handset available on surface or flush mount only)
Built-In Postal Lock Provision, EEPROM memory
Surface, Flush or Wall mounting styles Flush mount requires Flush Mounting Kit Enclosures are rated NEMA 4x

Connection methods noted will incur additional cost for required hardware and/or service subscriptions

Single-Line 20 character Super-Twist LCD Display (1/2 inch characters)
16 VAC (2 Power Transformers included)
Full Duplex Voice Communication
Stores up to 3000 Phone Numbers, 255 Area Codes
Max 8000 Wiegand Device (card codes), 10 Facility Codes
Transaction Buffer stores last 8000 Events
Control 3 Entry Points, expandable to 48 with Tracker Expansion Boards
Programmable Directory Codes (1 to 4 digits)
10 & 11-Digit Dialing Capability
31 Security (permission) Levels, 29 programmable with 4 Time Zones each
32 Holiday Schedules
4-Digit Entry Codes
Built-In Clock / Calendar
8 Hold Open Time Zones
Entry Code Time Zones
True Anti-Pass Back
Live Transactions feature (requires TCP/IP internet connection or RS-232 connection)

Environmental: 10ºF to 145ºF (-12°C to 62°C)
Heater Kit (P/N 2600-584) recommended when temperatures routinely fall below 10°F (-12°C)
ADA Compliant Handset Kit (P/N 1807-012) available on surface or flush mount only
Camera Ready: Optional B&W or Color CCTV Camera* *may require additional CCTV equipment
Shipping weight approximately 20-25 lb (9-11 kg)
